Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc/Upc APC Adapters/Connectors

Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC SC /UPC APC adapter/connectorProduct Features:Low Insertion lossLow PDLExcellent channel-to-channel uniformityHigh return loss and Good repeatabilityWide wavelength rangeApplications:LAN, WAN and Metro NetworksFTTH project & FTTX DeploymentsCATV SystemGPON, EPONFiber Optic

Featured Products

Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC SC /UPC APC adapter/connector

Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector


Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector




Product Features:

Low Insertion loss
Low PDL
Excellent channel-to-channel uniformity
High return loss and Good repeatability
Wide wavelength range


Applications:

LAN, WAN and Metro Networks
FTTH project & FTTX Deployments
CATV System
GPON, EPON
Fiber Optic Test Equipment
Data-base Transmit Broadband Net


Compliance:

Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
YD-T2000.1-2009
RoHS

Parameter4 Channel8 Channel16 Channel
MuxMuxDemuxMuxDemuxMuxDemux
Channel Wavelength(nm)1270~1610
Center wavelength Accuracy(nm)±0.5
Channel Spacing(nm)20
Channel Pass band(@-0.5dB bandwidth (nm)>14
Insertion Loss(dB)≤1.4≤2.6≤5.0
Channel Uniformity (dB)≤0.5≤0.5≤0.5
Channel  Ripple (dB)0.3
Isolation (dB)AdjacentN/A>30N/A>30
Non-adjacentN/A>40N/A>40
Insertion Loss Temperature Sensitivity (dB/ºC)<0.005
Wavelength Temperature Shifting (nm/ºC)<0.002
Polarization Dependent Loss (dB)<0.1
Polarization Mode Dispersion (PS)<0.1
Directivity (dB)>50
Return Loss(dB)>45
Maximum Power Handling(mW)500
Operating Temperature(ºC)-5~+75
Storage Temperature (ºC)-40~85
Package dimension(mm)1. L100 x W80 x H10 ( 2 CH~8CH Module)
2. L120xW800xH18  (9 CH~18CH Module)


Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector
Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector




Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector
Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector


Fiber Optic CWDM 6CH CWDM Mux/Demux Module with 6 LC Sc /Upc APC Adapter/Connector


1. Are you a manufacturer or trade company?

A: We are a FTTH manufacturer. Start with Huawei switch machine of HUAWEI in 1994, YUDA have gone through nearly 20 years in the fiber optic communication area. Now our factory is not only in Ningbo, but also have a production center in Jilin, covering an area nearly 23000 Sqm, owning 1500 workers.

2.Can I have a sample order for this product?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.


3. What about the lead time?

A: Sample needs 1-2 days, mass production time needs 1-2 weeks


4. How about your price?

A: We are supplying products with very competitive price based on good performance.


5.Do you offer OEM Service ?

A: We accept OEM, ODM. The cable size and material are customized. Our own logo and own design are welcome. We will produce according to your requirment and description


6. Do you offer guarantee for the products?

A: Yes, we offer 1-2 years warranty to our formal products.
