Product Features
· Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-LR4 Standard
· QSFP+ MSA compliant
· Compliant with QDR/DDR Infiniband data rates
· Up to 11.2Gb/s data rate per wavelength
· 4 CWDM lanes MUX/DEMUX design
· Up to 10km transmission on single mode fiber (SMF)
· Operating case temperature: 0 to 70ºC
· Maximum power consumption 2.5W
· LC duplex connector
· RoHS compliant
Applications
· 40GBASE-LR4 Ethernet Links
· Infiniband QDR and DDR interconnects
· Client-side 40G Telecom connections
Regulatory Compliance | ||
Feature | Standard | Performance |
Electromagnetic Interference (EMI) | FCC Part 15 Class B EN 55022:2010, Class B | Compatible with standards |
Electromagnetic susceptibility (EMS) | EN 55024:2010 | Compatible with standards |
Laser Eye Safety | FDA 21CFR 1040.10 and 1040.11 EN60950, EN (IEC) 60825-1,2 | Compatible with Class I laser product |
ESD
This transceiver is specified as ESD threshold 1kV for SFI pins and 2kV for all other electrical input pins, tested per MIL-STD-883, Method 3015.4 /JESD22-A114-A (HBM). However, normal ESD precautions are still required during the handling of this module. This transceiver is shipped in ESD protective packaging. It should be removed from the packaging and handled only in an ESD protected environment.
Laser Safety
This is a Class 1 Laser Product according to IEC 60825-1:2007. This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated (June 24, 2007).
Digital Diagnostic Functions
The following digital diagnostic characteristics are defined over the normal operating conditions unless otherwise specified.
Parameter | Symbol | Min | Max | Unit | Notes |
Temperature monitor absolute error | DMI_Temp | -3 | +3 | ºC | Over operating temperature range |
Supply voltage monitor absolute error | DMI_VCC | -0.1 | +0.1 | V | Over full operating range |
Channel RX power monitor absolute error | DMI_RX_Ch | -3 | 3 | dB |
|
Channel Bias current monitor | DMI_Ibias_Ch | -10% | +10% | mA |
|
Channel TX power monitor absolute error | DMI_TX_Ch | -3 | 3 | dB |
