Order Information
| Item | Unit | Parameter |
| Connector End 1# | -- | MPOF=MPO Female ,MPOM=MPO-male |
| End face 1# | -- | UPC , APC |
| Connector End 2# | -- | MPO-female , MPO-male |
| End face 2# | -- | UPC , APC |
| Fiber Count | -- | 8 , 12 , 24 MT Fiber |
| Fiber Type | SM(OS1 ,OS2), MM(OM1,OM2,OM3,0M4) | |
| Cable Diameter | (mm) | 3=3mm , 4=4mm |
| Cable Jacket | -- | LS=LSZH , PVC=PVC |
| Cable Length | (M) | L1=1M, 2M, 3M, 4M... |
| Loss | -- | LL=Low Loss(Elite) ,NA=Standard Loss |
Features:
· 100% pre-terminated and tested in factory to ensure the transfer performance
· Rapid configuration and network, reduce installation time
· Support 40G and 100G network applications
· Flammability: LSZH, OFNR, OFNP available
· Support up to 12F, 24F, 48F, 72F, 96F, 144F, customized products are available
· Polarity A (standard), B or C (12xFibre)
Application:
· Backbone connection in buildings and parks
· Backbone in Data Centers
· Backbone in industrial workshops
· Data Centre Infrastructure
· Emerging 40 and 100Gbps Protocols
Connector Performance
| Connector Mating | Insertion Loss Average | Insertion Loss Max | Return Loss |
| MPO/MTP® Elite (MM) | 0.10dB | 0.35dB | >30dB |
| MTP® (MM) | 0.20dB | 0.70dB | >30dB |
| MPO/MTP® Elite (SM) | 0.10dB | 0.35dB | >60dB |
| MTP® (SM) | 0.25dB | 0.75dB | >60dB |
