| Wavelength: | C17~C61 | Data Rate: | 10G SFP+ |
|---|---|---|---|
| Interface: | LC | Transmission Distance: | 80km |
| Compatiable: | HP, Huawei, H3C, Alcatel, Juniper Or Others | Fiber: | Dual Fiber |
| Certification: | CE RoHS FCC | Brands: | Can Be Customized |
| High Light: | 80km Ethernet Fiber Transceiver,10G Sfp Fiber Transceiver | ||
10G DWDM SFP+ Optical Transceiver C20~C61 80km DDM
DWDM SFP+ transceivers are designed to transmit and receive optical data over single mode optical fiber. Digital diagnostic functions are available via an I2C.This module is designed for single mode fiber and operates at a nominal wavelength of ITU Grid, C Band DWDM wavelength. It is with the SFP+ 20-pin connector to allow hot plug capability. The transmitter section uses a DWDM EML laser and is a class 1 laser compliant according to International Safety Standard IEC-60825.The receiver section uses a PIN detector and a limiting post-amplifier IC.
FEATURES :
Optical interface compliant to IEEE 802.3ae
Electrical interface compliant to SFF-8431
Specifications compliant with SFF 8472
Compliant with SFP+ MSA
Hot Pluggable
Low power consumption
Built-in digital diagnostic functions
Class 1 laser product complies with EN 60825-1
Power dissipation<1.5W
Case operating temperature range: -5°C to 70°C
APPLICATIONS :
10G Ethernet with FEC
10Gbps SONET/SDH ITU-T G.959.1 P1L1-2D2
10Gbps SONET/SDH ITU-T G.709
10G BASE-ZR/ZW
SFP footprint 80km 10G Fiber Channel
Ordering Information:
| Data Rate | distance | wavelength | LD | PD | Connector | DDM |
| 10G | 80km | DWDM(ITU Grid 17~61) | EML | APD | LC | Y |
| 10G | 40km | DWDM(ITU Grid 17~61) | EML | PIN | LC | Y |
