RoHS Compliant 40Gb/s QSFP PSM LR4 10km Optical ReceiverProduct Description
This product is a transceiver module designed for 2m-10km optical communication
applications. The design is compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 inputs channels (ch) of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4
CWDM channels signals, and converts them to 4 channel output electrical data.
The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311 and 1331 nm as
members of the CWDM wavelength grid defined in ITU-T G.694.2. It contains a duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. To minimize the optical dispersion in the long-haul system, single-mode fiber (SMF) has to be applied in this module.
The product is designed with form factor, optical/electrical connection and digital
diagnostic interface according to the QSFP+ Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.
· Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-LR4 Standard
· QSFP+ MSA compliant
· Compliant with QDR/DDR Infiniband data rates
· Up to 11.2Gb/s data rate per wavelength
· 4 CWDM lanes MUX/DEMUX design
· Up to 10km transmission on single mode fiber (SMF)
· Operating case temperature: 0 to 70ºC
· Maximum power consumption 2.5W
· LC duplex connector
· RoHS compliant
· 40GBASE-LR4 Ethernet Links
· Infiniband QDR and DDR interconnects
· Client-side 40G Telecom connections
Laser SafetyThis transceiver is specified as ESD threshold 1kV for SFI pins and 2kV for all other electrical input pins, tested per MIL-STD-883, Method 3015.4 /JESD22-A114-A (HBM). However, normal ESD precautions are still required during the handling of this module. This transceiver is shipped in ESD protective packaging. It should be removed from the packaging and handled only in an ESD protected environment.
This is a Class 1 Laser Product according to IEC 60825-1:2007. This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated (June 24, 2007).
Digital Diagnostic Functions
The following digital diagnostic characteristics are defined over the normal operating conditions unless otherwise specified.
Temperature monitor absolute error
Over operating temperature range
Supply voltage monitor absolute error
Over full operating range
Channel RX power monitor absolute error
Channel Bias current monitor
Channel TX power monitor absolute error
Packaging & Shipping
